Draper Vertical Transmission Jack, 1000kg 19788

Description

Expert Quality, hydraulic vertical transmission jack with a telescopic twin stage ram. Fitted with a lowering control system (LCS) which safely lowers the load precisely into position and the safety overload valve provides added user protection. Operated via the twin position and 'Quick Lift' foot pedal for hands-free operation and attached with chain straps for added support and adjustable supporting struts for increased stability. The nylon wheels provide a quieter and smoother operation whilst preventing damage to workshop floors and the side-mounted handle aids positioning and increases manoeuvrability. The fully adjustable saddle can accept a wide variety of gearboxes/components and the forward, backward and side-to-side tilt features aids the user further.

Specifications

Capacity: 1,000kg
Minimum height: 940mm
Maximum height stage 1: 1,430mm
Maximum height stage 2: 1,940mm
Castor diameter: 75mm
Base size: 740 x 640mm
Saddle type: Adjustable
Chain length: 1,495mm
Weight: 67kg

Standards

Manufactured to EN1494 Specification

Draper Vertical Transmission Jack, 1000kg 19788

Product form

New Website Coming Soon!

We're working hard to bring you an improved shopping experience. In the meantime, we're here to help!

📞 Need This Product?

Contact us at 01604 720272
or email sales@rockbottomnorthampton.co.uk

🏪 Local Pick-Up Available
2 Ashburnham Road NN1 4QY
⚠️ Please contact us first before visiting the store

⭐ Thanks for bearing with us during this exciting transition!

Expert Quality, hydraulic vertical transmission jack with a telescopic twin stage ram. Fitted with a lowering control system (LCS) which... Read more

SKU: 19788-DRA
Barcode: 5010559197880

    £743.49 Incl. VAT

    Description

    Expert Quality, hydraulic vertical transmission jack with a telescopic twin stage ram. Fitted with a lowering control system (LCS) which safely lowers the load precisely into position and the safety overload valve provides added user protection. Operated via the twin position and 'Quick Lift' foot pedal for hands-free operation and attached with chain straps for added support and adjustable supporting struts for increased stability. The nylon wheels provide a quieter and smoother operation whilst preventing damage to workshop floors and the side-mounted handle aids positioning and increases manoeuvrability. The fully adjustable saddle can accept a wide variety of gearboxes/components and the forward, backward and side-to-side tilt features aids the user further.

    Specifications

    Capacity: 1,000kg
    Minimum height: 940mm
    Maximum height stage 1: 1,430mm
    Maximum height stage 2: 1,940mm
    Castor diameter: 75mm
    Base size: 740 x 640mm
    Saddle type: Adjustable
    Chain length: 1,495mm
    Weight: 67kg

    Standards

    Manufactured to EN1494 Specification
